GYS, PROTIG 201 DC FV, 065772, OPTIMISED DC WELDING

FEATURES

Arc starting in TIG:

Choose between:

• High frequency start to begin welding without touching the tungsten to the work piece for an uncontaminated start

OR

• LIFT TIG – In situations where nearby electrically sensitive equipment is present (ie welding modern cars).  Touch the tungsten electrode on the work piece and lift to start the arc.

Trigger Control

• 2T – Press the torch button to begin and release to finish the weld.
• 4T – Press torch button to start and press again to finish the weld.
• 4T Log – Enables switching between 2 operator pre-set welding intensities (hot current and cold current) by a short press on the trigger.

Optimised DC TIG Welding

• Secondary regulation: ensures optimum arc stability and constant current in all positions.
• TIG DC Pulse : controls the temperature of the weld puddle, limiting deformation and thus allows the assembly of thin sheets from 0.3 mm.
• SPOT : Fast and precise spot welding, ideal before welding thin sheet metal.
• Automatic torch detection: compatible with latch torches and double button.

MMA Welding

Benefitting from the following features:

Adjustable Arc Force:  Instantaneous increase in welding current in difficult welding conditions.

Anti Sticking: Allows easier arc starting and helps prevent rod sticking to the material.

Hot Start: Makes it easier to arc with any type of metal (Low Hot Start: For thin metal sheets – high Hot Start for metals that are difficult to weld such as dirty or oxidized sheets)

RUGGED BUILD

• Reinforced body and shockproof rubber pads on the corners.
• Light (10 kg), compact and easy to move on-site.
• Protected against overvoltage up to 400 V (PROTEC 400).
• Connectivity for remote control (manual or pedal)
• MADE IN FRANCE
